Audient EVO 4

Audient EVO 4

N$4,199.00 NAD
N$4,199.00 NAD
Sale Sold out
Taxes included. Contact us for shipping rates
NOTIFY ME WHEN IN STOCK

Brand: Audient
Model: EVO 4

Capture your microphones and instruments and start recording audio directly to your computer with EVO 4’s intuitive feature set. Combining leading tech specs with incredible performance and sound quality, EVO 4 is the perfect interface for beginners and pros alike.

At the time of writing, the EVO range is compatible with the following operating systems:

Mac
macOS 10.13.6 (High Sierra)
macOS 10.14.X (Mojave)
macOS 10.15.X (Catalina)
macOS 11.1.x (Big Sur)
macOS 12.3.x (Monterey)
macOS 13.x (Ventura)
macOS 14.x (Sonoma)

Requirements:
*Mac
Intel CPU or Apple Silicon
1GB RAM Minimum
*Windows
Windows 10
Windows 11

Overview

• 2 x EVO Mic Pres
• Class Leading Converters
• Smartgain
• Smart Touchpoints
• JFET Instrument Input
• Speaker Outputs
• Headphone Output
• Compatible with Mac, Windows and iOS
• Monitor Mix
• Monitor Pan
• Audio Loop-back
• USB2.0 Bus Powered
• Phantom Power
• DAW Controlled Mic Pre
• 24bit / 96kHz
• Free Software + Plugins

Specifications

*Microphone Preamplifier
Mic Gain Range: 58dB
Line Gain Range: 58dB (-10dB pad)
Phantom Power: 48v +/-4v @ 10mA/Channel
Mic EIN: <-128dBu
CMRR: >85dB @ 1kHz
Maximum Input Level: +16dBu
Input Impedance (Mic): >3kΩ Balanced
Input Impedance (Line): >10kΩ Balanced
Frequency Response: +/-0.5dB 10Hz to 40kHz
Crosstalk: <-105dBu @ 1kHz & 10kHz
THD+N @ 0dBu (1kHz): <0.0015%
SNR: 100dB
XLR: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)

*D.I
D.I Gain Range: 58 dB
Maximum Input Level: +10dBu
Input Impedance: 1MegΩ Unbalanced
Frequency Response +/-0.5dB 10Hz to 20kHz
THD+N @ 0dBu (1kHz): <0.3%
SNR: 100dB
1/4” Jack: TIP (Hot) & SLEEVE (Shield)

*ADC Inputs
Digital Reference Level: 0dBFS = +8dBu
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -105dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz): <0.001%
Dynamic Range: 113dB A-weighted

*DAC Outputs
Maximum Output Level: +11dBu
Digital Reference Level: 0dBFS = +11dBu
Output Impedance: <100Ω Balanced
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: <-110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): <0.0015%
Dynamic Range: 113dB A-weighted
1/4” Jack: TIP (Hot), RING (Cold) & SLEEVE (Shield)

*Headphone Output
Output Impedance: <50Ω
Frequency Response: +/-0.5dB 10Hz to Fs/2
Crosstalk: -110dBu @ 1kHz
THD+N @ -1dBFS (1kHz): <0.0015%
Dynamic Range: 113dB A-weighted
Max Level Into 30ohms: +0.5dBu, 0.0025% THD+N, 1.16Vpk Power: 45mW
Max Level Into 60ohms: +4.22dBu, 0.0015% THD+N, 1.78Vpk Power: 52mW
Max Level Into 600ohms: +10.1dBu, 0.0018% THD+N, 3.52Vpk Power: 20mW
1/4” Jack: TIP (Left), RING (Right) & SLEEVE (Shield)

*DSP Mixer Roundtrip Latency:
(in to out)
44.1 kHz 0.594ms
48.0 kHz 0.552ms
88.2 kHz 0.302ms
96.0 kHz 0.281ms

*DAW Playback Latency
@ 32 Sample Buffer for Software Instrument Playback
44.1 kHz ~2.5ms
96.0 kHz ~2ms

*DAW Roundtrip Software Monitoring Latency
@ 32 Sample Buffer (in to out)
44.1 kHz 5ms
96.0 kHz 4.1ms
Latency – performance may vary as stability at these low buffer sizes is dependant on many factors including CPU load, operating system and performance of other drivers.

*USB 2.0 High Speed
No. Of Input Channels 2 Analogue
No. Of Output Channels 2 Analogue
Connector: USB Type-C
Included Cables: 1m USB 2.0 Type-C to USB Type-A

*Weight & Dimensions
Weights: Unit: 360g
Packaged: 600g
Dimensions: Unit: 140mm (w) x 67mm (h) x 67mm (d)
Packaged: 172mm (w) x 88mm (h) x 97.5mm (d)
