Ortofon - Stylus CC MKII Club

Brand: Ortofon
Model: MKII Club

The replacement stylus offers a tactile feedback when seating, indicating a snug and secure fit, while a cut-out area in the front allows for far more accurate needle drops.

Channel balance at 1 kHz
1 dB
Output voltage at 1 kHz, 5cm/sec
8 mV
Channel separation at 1 kHz
25 dB
Tracking ability at 315Hz
100 μm
Compliance, dynamic, lateral
14 μm/m N
Stylus type
Special Elliptical
Stylus tip radius
r/R 13/25 μm
Tracking force range
2 - 4 g
Tracking force, recommended
3 g
Cartridge weight
stylus = 1 g
Download userguide
